AIS140 IRNSS 2G
AIS-140 Certified – Approved for public transport by ARAI
Tamper & Power Cut Alerts – Real-time safety notifications
Built-in Battery Backup – Operates up to 6 hours without vehicle power
Panic Button Support – Emergency alert integration as per AIS-140 norms
IP67 Rated – Dust and water-resistant enclosure
Live Tracking & Trip History – Real-time updates with historical route playback
Supports All Vehicles – Wide voltage range (9V–36V) for compatibility
I COMPASS 2G
I COMPASS 4G EV
I COMPASS 2G - Specifications
- Quad Band GSM – 850/900/1800/1900 MHz
- GNSS and IRNSS Downlink with 1.5 meters Accuracy
- Superior FOTA(Firmware Over The Air) Capability for Updating the Device Firmware remotely
- Two way GPRS Communication for controlling the device
- 4 Digital Inputs (One is dedicated for Ignition)
- 2 Digital Outputs
- 2 Analogue Inputs
- 1-wire Protocol
- Serial – RS485 Communication
- Accelerometer and Gyro sensor
- Waterproof with IP65 grade protection
- Embedded SIM with Dual Operator Capability
- Variable DC Power input Range from 8 – 36 Vdc
- All antennas inbuilt (Tamper Proof)
I COMPASS 4G EV - Specifications
- Quad Band GSM – 850/900/1800/1900 MHz
- GNSS and IRNSS Downlink with 1.5 meters Accuracy
- Superior FOTA (Firmware Over The Air) Capability for Updating the Device Firmware remotely
- Two way GPRS Communication for controlling the device
- 4 Digital Inputs (One dedicated for Ignition)
- 2 Digital Outputs
- 2 Analog Inputs
- 1-wire Protocol
- Serial – RS485 Communication
- 1xCAN 2.0B for Vehicle Diagnostics over CAN
- Accelerometer and Gyro sensor
- Waterproof with IP65 grade protection
- Embedded SIM with Dual Operator Capability
- Variable DC Power input Range from 9 – 90 Vdc
- All antennas inbuilt (Tamper Proof)
